INNOVATIVE LED LIGHTING TECHNOLOGY

Pentaled 30E is a compact hi-tech device that guarantees a high level of performance. Its 30 elliptical reflectors divided into 6 modules each include 5 LEDs that provide 160,000 LUX light

- choice between 4,500 and 5,000 °K: by simply pressing a digital button, the surgeon can choose between two white light temperatures
- electronic visualization: the innovative lenses allow the surgeon to electronically increase/decrease the light field, without altering the intensity of the light
- electronic comfort: the indirect light creates 3D illumination of the work area without shadows and without the risk of glare
- only white light to avoid the risk of perception of color temperature variations or colored shadows
- electronic depth: the center of the light is equipped with an additional LED module designed to reflect the depth light. The surgeon can therefore work with perfect 3D lighting
- battery and high definition camera on request: optional battery with automatic charger (4 hours of battery life) and integrated high definition camera (only for ceiling and wall models)

1 pc.

- Light intensity at 1 m distance (Ec): Klx 160
- Color temperature - selectable °K 4500 - 5000
- Color rendering index (CRI) Ra 96
- Light fields (electronic regulation) 16-30 cm
- Ø of the light field at 10% of the light intensity (d10) 160 mm
- Ø of the light field at 50% of the light intensity (d50) 80 mm
- Ratio between the radiated energy Ee and the illumination Ec W/m2 540
- Average LED lifespan 50,000 hours
- Power supply 100-240 V - 50-60 Hz - 70VA
- Standards IEC 60601-2-41 - 2007/47/EC
- Made in Italy
